Product Summary
The 1N6478-E375 is a surface mount glass passivated junction rectifier.
Parametrics
1N6478-E375 absolute maximum ratings: (1)Maximum repetitive peak reverse voltage VRRM: 50Volts; (2)Maximum RMS voltage VRMS: 35Volts; (3)Maximum DC blocking voltage VDC: 50Volts; (4)Maximum average forward rectified current at I(AV): 1.0 Amp; (5)Peak forward surge current, IFSM: 30.0 Amps; (6)Maximum instantaneous forward voltage at 1.0A, VF: 1.1 Volts; (7)Maximum DC reverse current: 10.0μA; (8)Maximum full load reverse current, full cycle average at TA=75℃ IR(AV): 100.0 μA; (9)Typical junction capacitance (NOTE 1) CJ: 8.0 pF; (10)Operating junction and storage temperature range TJ, TSTG: -65 to +175 ℃.
Features
1N6478-E375 features: (1)Plastic package has Underwriters Laboratory Flammability Classification 94V-0; (2)For surface mount applications; (3)High temperature metallurgically bonded construction; (4)Glass passivated cavity-free junction; (5)Capable of meeting environmental standards of MIL-S-19500; (6)High temperature soldering guaranteed: 450℃/5 seconds at terminals.
