T495D107K016ATE125

T495D107K016ATE125, Kemet, SMD, solid tantalum chip capacitor, 13.2 μA, 700 mΩ, 357 mA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.10~100.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.10~100.00

PartNumber:: T495D107K016ATE125

Brand:: Kemet Corporation - KEMET | Pack: SMD | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Mable's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-11-30

From Other Seller

Part Number:T495D107K016ATE125
US $0.10 - 100.00
IRF3205

US $0.80 - 2.50 / Piece
(0) Remove
SLA4060

US $0.80 - 1.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The T495D107K016ATE125 is a solid tantalum chip capacitor.

Parametrics

T495D107K016ATE125 absolute maximum ratings: (1)DC Leakage μA @ 25℃ Max: 13.2; (2)DF% @ 25℃, 120 Hz, Max: 12.0; (3)ESR mΩ @ 25℃ 100 kHz Max: 700; (4)Ripple Current mA rms @ 25℃, 100 kHz Max: 396 ; (5)Ripple Current mA rms @ 85℃, 100 kHz Max: 357 ; (6)Ripple Current mA rms @ 125℃, 100 kHz Max: 159.

Features

T495D107K016ATE125 features: (1)Designed for very low ESR; (2)High ripple current capability; (3)High surge current capability; (4)100% accelerated steady-state aging; (5)100% Surge Current test; (6)Meets or Exceeds EIA Standard 535BAAC; (7)Available tested per DSCC Dwg. 95158; (8)Operating Temperature: -55℃ to +125℃; (9)New Extended Values for Low ESR; (10)Low Equivalent Series Inductance (2.5nH ESL); (11)Precision-molded, laser-marked case; (12)Symmetrical, compliant terminations; (13)Taped and reeled per EIA 481-1; (14)RoHS Compliant & Leadfree Terminations.
