Product Summary
The CD4148WTP is a switching diode.
Parametrics
CD4148WTP absolute maximum ratings: (1)Forward Power Dissipation, Ptot: 200mW; (2)Power derating above 25℃, Ptot: 1.6 mW/℃; (3)Junction Temperature, Tj: 150℃; (4)Thermal Resistance Junction to Ambient air, RθJA: 375℃/W; (5)Operating& Storage Temperature range, Tstg: -55 to 150℃.
Features
CD4148WTP features: (1)Silicon epitaxial planar diode; (2)SMD chip pattern; (3)available in various dimension included 1206 & 0805; (4)Leadfree and RoHS compliance components; (5)For small signal switching and operating ambient temperature less than 55℃; (6)voltage withstand less than 60V; (7)not suitable for AC switching input as rectified circuit and high reverse voltage location; (8)CD4148WTN is suitable for those application.
Diagrams
 |
