Product Summary
The LQW18AN18NJ00D is a chip inductor. It is specifically designed for high frequency applications. It is designed to realize stable characteristics in high frequency range applying integrated multilayer process. The integrated multilayer process enables a wide range of inductance values with tight tolerance.
Parametrics
LQW18AN18NJ00D absolute maximum ratings: (1)Maximum DC Current: 550 mAmps; (2)Maximum DC Resistance: 0.16 Ohms; (3)Self Resonant Frequency: 5500 MHz; (4)Q Minimum: 40; (5)Operating Temperature Range: - 55 to + 125℃; (6)Termination Style: SMD/SMT; (7)Package / Case: 0603 (1608 metric); (8)Dimensions: 0.800 mm W x 1.6 mm L x 0.800 mm H; (9)Packaging: Reel; (10)Series: LQW18A; (11)Test Frequency: 100 MHz.
Features
LQW18AN18NJ00D features: (1)High-Q, stable inductance in high frequency is achieved by the original structure that minimizes stray capacitance. It is suitable for the high frequency circuits of mobile communication equipment; (2)The small size of LQG15H (1.0x0.5x0.5mm) is suitable for small and low profile mobile equipment; (3)The external electrodes with nickel barrier structure provide excellent solder heat resistance.; (4)Wide variation in inductance value: 1-10nH (E24 step); 10-120nH (E12 step).
