Product Summary
The 1SMA5925BT3G is a 1.5 Watt plastic surface mount zener voltage regulator.
Parametrics
Absolute maximum ratings: (1)DC power dissipation @TL=75鈩? 1.5W; measured zero lead lentgh derate above 75鈩? 20mW/D: 20mW/鈩? (2)thermal resistance, junction-to-lead, R胃JL: 50鈩?W; (3)DC power dissipation @TA=25鈩? PD: 0.5W; derate above 25鈩? 4.0mW/鈩? (4)thermal resistance, junction-to-ambient, R胃JA: 250鈩?W; (5)operating and storage temperature range, TJ, Tstg: -65 to +150鈩?
Features
Features: (1)Standard Zener Breakdown Voltage Range - 3.3 V to 68 V; (2)ESD Rating of Class 3 (>16 kV) per Human Body Model; (3)Flat Handling Surface for Accurate Placement; (4)Package Design for Top Slide or Bottom Circuit Board Mounting; (5)Low Profile Package; (6)Ideal Replacement for MELF Packages; (7)Pb-Free Packages are Available.
