Product Summary

The RC1608J223CS is a chip resisitor which is useful for derating voltage, current controlling in circuit and surface mounting is available.

Parametrics

Absolute maximum ratings: (1)Power Rating: 100 mW; (2)Resistance: 22.0 kΩ; (3)Size-Height: 450 μm; (4)Size-Length: 1.60 mm; (5)Size-Width: 800 μm; (6)Voltage Rating (DC): 10.0 V; (7)Insulation Resistance: 1.00 GΩ (min); (8)Operating Temperature: -55.0 ℃ (min); (9)Case/Package: 0603; (10)RoHS: Non-Compliant.

Features

Features: (1)very small, thin, and light weight; (2)both flow and reflow soldering are applicable; (3)owing to the reduced lead inductance, the high frequency characteristic is excellent; (4)suitable size and bulk packing for surface mount assembly; (5)reel type and bulk type packaging are applicable.

Diagrams
