Product Summary

The LMK212BJ106KG-T is a u-cap 150mA linear voltage regulator in the SOT-25 package. This regulator has very low dropout voltage and very low ground current. It is designed especially for hand-sets, battery-powered devices and can be controlled by a CMOS or TTL.

Parametrics

Absolute maximum ratings: (1)Input supply voltage: -0.4 to +16 V; (2)Enable Input Voltage: -0.4 to +16 V; (3)Power Dissipation: 500 mW; (4)Junction Temperature Range: -40 to +125 鈩? (5)Storage Temperature Range: -60 to +150 鈩? (6)Lead Temperature Time: 260 (5 Sec) 鈩?

Features

Features: (1)Low dropout voltage regulator; (2)Low quiescent current and guaranteed 150mA output; (3)Zero off-mode current.
